Buffer Vessels for Optimal System Performance

Heating and chilled water buffer vessels from 10 to 10,000 litres, with the commercial range starting from 300 litres and bespoke sizes built to order, to stop heat pumps, boilers and chillers short cycling.

  • Buffer vessels from 10 L to 10,000 L
  • Commercial range from 300 L
  • 10–50 L inline volumisers
  • Heating and chilled water
  • PU injection foam insulation
  • Bespoke sizes are our speciality

Lead time (ready for dispatch) – calorifiers, buffer vessels and low loss headers by capacity

Checking today’s lead times…

Need it sooner? Call us — we can often expedite.

Specifications Datasheets & downloads

  • Made in Manchester
  • ISO 9001
  • PED
  • UKCA
SS Buffer 50-300 L (standard range)
SS Buffer 50-300 L (standard range)
Capacity (litres)50100150180210250300
Height (mm)51079211541280146817182031
Diameter (mm)550550550550550550550
Standing heat loss (W)22.541.2563.7574.1784.5891.6797.5
ErP classABCCCCC
Product code50SSBUFF100SSBUFF150SSBUFF180SSBUFF210SSBUFF250SSBUFF300SSBUFF
Empty weight (kg)12202833384348
Full weight (kg)62120178213248293348
Heat loss (kWh/24h)0.540.991.531.782.032.202.34
3 kW immersion1111111
Packaged dimensions H × W × D (mm)610 x 600 x 600892 x 600 x 6001254 x 600 x 6001380 x 600 x 6001568 x 600 x 6001818 x 600 x 6002131 x 600 x 600
Packaged weight (kg)55606570758085
28mm compression fittings5555555
½” female stat pockets1233333
½” female drainNoYesYesYesYesYesYes
3kW immersion heater fittedYesYesYesYesYesYesYes
ErP fiche volume (litres)52104151178213246296
Maximum working pressureSame for every size
6 Bar G (hydraulically tested to 10.05 Bar G)
SSBUFF stainless steel buffer vessel product information sheet (PDF) (opens in a new tab)
Buffer vessels: standard datasheet sizes
Buffer vessels: standard datasheet sizes
Capacity (litres)600750800100015002000250030004000500060008000
Height (mm)164219812100185019502200250028402500275028502750
Diameter (mm)850850850100012001300130013001600170017002100
Standing heat loss (W)136142158184201.25229.58273.3312.5371.25432.5604.16867.08
Product code600SSBUFF750SSBUFF800SSBUFF1000SSBUFF1500SSBUFF2000SSBUFF2500SSBUFF3000SSBUFF4000SSBUFF5000SSBUFF6000SSBUFF8000SSBUFF
Empty weight (kg)1782202853405006007001,0201,2001,4002,0402,400
Full weight (kg)7789701,0851,3402,0002,6003,2004,0205,2006,4008,04010,400
Packaged weight (kg)18823029535051061071010301210141020502415
ConnectionsDrain 1”; B 1”; D 1” (female BSP)Drain 1”; B 1”; D 1” (female BSP)Drain 1”; B 1”; D 1” (female BSP)Drain 1”; B 1½”; D 1¼” (female BSP)Drain 1”; B 1½”; D 1½” (female BSP)Drain 1”; B 2”; D 1½” (female BSP)Drain 1”; B 2”; D 2” (female BSP)Drain 1”; B 1¼”; D 2” (female BSP)Drain 1”; B 1½”; D 2½” (female BSP)Drain 1”; B 1½”; D 2½” (female BSP)Drain 1”; B 2”; D 2½” (female BSP)Drain 1”; B 2”; D 2½” (female BSP)
ErP fiche volume (litres)59875383699415021994249429983998500460028004
Stainless steel buffer vessel 600L to 8000L product information sheet (PDF) (opens in a new tab)
Inline volumisers 10L and 20L
Inline volumisers 10L and 20L
Capacity (litres)1020
Height (mm)396696
Width (mm)270270
Standing heat loss (W)1822
ErP classAA
Max working pressure6 Bar G6 Bar G
Max flow rate60 litres per minute60 litres per minute
Product codeUK.INLINE.10UK.INLINE.20
Empty weight (kg)710
Full weight (kg)1730
Packaged dimensions H × W × D (mm)700 x 300 x 300700 x 300 x 300
Packaged weight (kg)811
Insulation thickness35mm35mm
Connections28mm compression28mm compression
Maximum working pressure6 Bar G6 Bar G
Maximum flow rate60 litres per minute60 litres per minute
Inline volumiser 10L and 20L product information sheet (PDF) (opens in a new tab)
Inline volumisers 25L and 50L
Inline volumisers 25L and 50L
Capacity (litres)2550
Height (mm)850800
Width (mm)270350
Standing heat loss (W)2244
ErP classAC
Max working pressure6 Bar G6 Bar G
Max flow rate60 litres per minute60 litres per minute
Product codeUK.INLINE.25UK.INLINE.50
Empty weight (kg)714
Full weight (kg)1760
Packaged dimensions H × W × D (mm)950 x 400 x 400900 x 500 x 400
Packaged weight (kg)815
Insulation thickness35mm35mm
Connections28mm compression28mm compression
Maximum working pressure6 Bar G6 Bar G
Maximum flow rate60 litres per minute60 litres per minute
Inline volumiser product information sheet (PDF) (opens in a new tab)

Figures are from our current product data; each range’s product information sheet is linked under its table. Connection positions are confirmed on the drawing for each order. Other sizes and configurations are built to order.

In detail

About Buffer Vessels

World Heat Cylinders manufacture heating and chilled water buffer vessels in Manchester, specifically designed to enhance the efficiency and stability of modern HVAC systems. Indeed, a buffer vessel, also known as a buffer tank or thermal store (for heating circuits), adds essential thermal mass to a system. This, subsequently, helps to optimise the performance of primary heat sources or chillers, particularly those prone to short cycling.

Key Benefits of Installing System Buffer Tanks

Consequently, integrating a correctly sized buffer tank into your heating or cooling system offers several significant advantages:

  • Reduced Equipment Cycling: Crucially, buffer tanks minimise frequent starting and stopping of boilers, heat pumps, or chillers.
  • Improved Energy Efficiency: Furthermore, by allowing equipment to run for longer, more optimal periods, these thermal stores help to improve overall system energy efficiency.
  • Enhanced System Stability: They provide a thermal buffer, thereby ensuring more stable operating temperatures and preventing rapid fluctuations.
  • Optimised Heat Pump Performance: Particularly for air source and ground source heat pumps, buffer tanks ensure minimum system volume requirements are met, which is, in fact, essential for efficient operation and defrost cycles.
  • Support for Low-Loss Headers: Additionally, they are often used in conjunction with low-loss headers to decouple hydraulic circuits effectively.
  • Storage for Multiple or Modulating Sources: Moreover, this allows for better management of systems with multiple or modulating heat sources, such as biomass boilers.

Applications for World Heat Cylinders Thermal Buffers

Our versatile tanks can be connected to many different types of systems, including, for example:

  • Heating systems with gas, oil, or electric boilers
  • Biomass boiler installations
  • Air source and ground source heat pump systems
  • Solar thermal systems (albeit as part of a combined setup)
  • Air conditioning and chiller circuits (chilled water buffer vessels)
  • Combined heating and cooling applications

Essentially, any system that benefits from added thermal mass or hydraulic separation can utilise our buffer units.

Buffer Tank Materials, Sizes & Specifications

We manufacture these essential system components from a range of high-quality materials to suit diverse applications and budgets, for instance:

  • Mild Steel Buffer Vessels: A cost-effective solution for closed-loop heating systems.
  • Stainless Steel Buffer Vessels: In Duplex stainless steel.
  • Galvanised Mild Steel Buffer Vessels

Our buffer vessels run from compact 10-litre units (often referred to as volumisers or inline buffers) up to 10,000-litre tanks, with the commercial range starting from 300 litres and bespoke sizes built to order. Buffer vessels made to the volume you need, within a tolerance, are available up to a maximum of 1,000 litres. Because of this extensive range, we can cater for any building, from a small canal boat requiring minimal buffering to a large office block, school, or hospital with significant system volume needs.

All our buffer units can be supplied with a high-quality cased finish. Furthermore, they feature high-density, high-efficiency polyurethane injection insulation. This, consequently, ensures they meet current UK building regulations and Energy-Related Products (ErP) legislation where applicable.

Custom Buffer Tank Design & Manufacturing

As with all World Heat Cylinders products, we offer a comprehensive bespoke design service. Consequently, you can specify exactly what heat inputs, outputs, connection sizes, and orientations you require for your custom tank. We can, for example, manufacture buffer tanks as vented or pressurised units. Moreover, options include direct connections, indirect coils (single or twin coil configurations) for multiple heat sources, or specialist internal baffling.

Indeed, our experienced design engineers are available to assist you in specifying or designing the perfect buffer solution tailored to your unique project requirements. Whether it's a non-standard size, specific pressure rating, or unique port configuration, we have the expertise to deliver.

Contact Us for Your Buffer Tank Requirements

To discuss your heating or chilled water buffer system requirements, or for assistance with sizing and specification, please get in touch with our technical sales team.

Therefore, call us on 0161 343 8610, email sales@whcylinders.co.uk, or visit our contact page.

Need this tailored to your project or system?

Different connections, coil, size, controls or finish: our design team builds to your requirements.
We also build own-brand ranges for OEM partners.

Frequently asked questions

What sizes do buffer vessels come in?
Buffer vessels from 10 to 10,000 litres, with the commercial range starting from 300 litres, and bespoke sizes built to order.
Why install a buffer vessel?
To add system volume and stop heat pumps, boilers and chillers short cycling.
How long does it take to get my cylinder?
Lead times vary by product – call 0161 343 8610 for today’s lead time on your product.
Can I get a size or configuration that isn't listed?
Yes — other sizes and configurations are built to order. Request a quote and our technical team will come back with a quotation.
