Heat Geek Super Cylinder
A high-performance heat pump cylinder designed by Heat Geek and manufactured by World Heat: a stainless steel unvented hot water cylinder with a large corrugated stainless steel coil for heat pumps and other low-temperature heat sources. Sizes from 150 to 300 litres.
- Designed by Heat Geek, manufactured by World Heat
- 150–300 L standard sizes
- Heat pump coil 4 m²
- ErP class B–C
- Made in our UK factory
Specifications Datasheets & downloads
Made in Manchester- ISO 9001
- WRAS
- G3
Technical data
Specifications
Heat Geek Super Cylinder
| Capacity (litres) | 150 | 180 | 210 | 250 | 300 |
|---|---|---|---|---|---|
| Product code | 150HEATGEEKSLIM | 180HEATGEEKSLIM | 210HEATGEEKSLIM | 250HEATGEEK | 300HEATGEEK |
| Height (mm) | 1,474 | 1,690 | 2,003 | 1,718 | 2,031 |
| Diameter (mm) | 475 | 475 | 475 | 550 | 550 |
| Empty (kg) | 43 | 48 | 58 | 65 | 70 |
| Heat pump coil (m²) | 4 | 4 | 4 | 4 | 4 |
| 3 kW immersion | 1 | 1 | 1 | 1 | 1 |
| Secondary return | Yes | Yes | Yes | Yes | Yes |
| Heat loss (kWh/24h) | 1.28 | 1.38 | 1.85 | 2.10 | 2.29 |
| ErP | B | B | C | C | C |
| Packaged dimensions H × W × D (mm) | 1550 x 475 x 475 | 1750 x 475 x 475 | 2100 x 475 x 475 | 1920 x 600 x 600 | 2230 x 600 x 600 |
| Packaged weight (kg) | 60 | 65 | 70 | 75 | 80 |
| Expansion vessel | 12L | 12L | 18L | 18L | 24L |
| Pressure reducing / relief valve | 3.0 bar / 6.0 bar | 3.0 bar / 6.0 bar | 3.0 bar / 6.0 bar | 3.0 bar / 6.0 bar | 3.0 bar / 6.0 bar |
| T&P valve | 7.0 bar / 90 °C | 7.0 bar / 90 °C | 7.0 bar / 90 °C | 7.0 bar / 90 °C | 7.0 bar / 90 °C |
| Insulation thickness | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Expansion vessel charge pressure | 3.0 bar | 3.0 bar | 3.0 bar | 3.0 bar | 3.0 bar |
| Maximum working pressure | Primary 3.0 bar, secondary 6.0 bar | Primary 3.0 bar, secondary 6.0 bar | Primary 3.0 bar, secondary 6.0 bar | Primary 3.0 bar, secondary 6.0 bar | Primary 3.0 bar, secondary 6.0 bar |
| Test pressure | 10.5 bar | 10.5 bar | 10.5 bar | 10.5 bar | 10.5 bar |
| Actual stored-water capacity (litres) | 146 | 176 | 205 | 244 | 293 |
- ConnectionsSame for every size
- Cold water inlet: 22 mm compression
- Hot water draw-off: 22 mm compression
- Primary coil stubs (×2): 28 mm plain stub (80 mm)
- Secondary return: 22 mm compression
- T&P relief valve boss: ½" BSP female
- Drain valve boss: ½" BSP female
- Thermostat pockets: 22 mm dry pocket
- Immersion heater boss: 1¾" BSP female
- Coils (area and duty)Same for every size
- 4.0 m² heat pump coil: 2.2 kW per K of temperature difference between coil and stored water at 30 L/min primary flow
- Valves suppliedSame for every size
- 3 kW Incoloy 1¾" BSP immersion heater with thermostat and manual-reset thermal cut-out
- 4.0 m² MH 211 K DN32 corrugated stainless steel coil
- Cold water inlet control group: pressure reducing valve (set to 3.0 bar), line strainer, non-return valve, expansion relief valve (6.0 bar) and balanced cold connection
- Temperature and pressure (T&P) relief valve, 7.0 bar / 90 °C
- Potable water expansion vessel, pre-charged to 3.0 bar
- Tundish (15 mm inlet, 22 mm outlet)
- Drain valve (½" BSP with hose union)
- 22 mm compression fittings on the cold inlet, hot draw-off and secondary return
Figures are from our current product data; each range’s product information sheet is linked under its table. Connection positions are confirmed on the drawing for each order. Other sizes and configurations are built to order.
Must be installed by a qualified unvented (G3) installer and registered with building control.
Documents
Datasheets & downloads
Installation & service manuals
ErP labels & data
Certificates
Can’t find a document? Search the downloads library, browse all product datasheets and manuals, or email sales@whcylinders.co.uk.
In detail
About Heat Geek Super Cylinder
The Heat Geek Super Cylinder is a high-performance heat pump cylinder designed by Heat Geek and manufactured by World Heat in our UK factory. Its large corrugated stainless steel coil suits the low flow temperatures of heat pumps, as well as boilers and other heat sources. Every model comes with its unvented kit, listed in the specification above and in the installer manual.
